Toolkit RC M6D Charger

TOOLKITRC M6D - DUAL CHANNEL 500W 25A DC CHARGER

A compact dual channel charger with a 2.4" LCD screen @500W

This is the new ToolkitRC M6D dual port 500w charger, a great way to charge multiple batteries without the risk of using a parallel charging board.

The M6D is a DC charger so make sure to pickup a power supply for it from our wide variety of Power Supplies!

FEATURES

• 2.4" LCD screen
• Dual channel
• Asynchronous and synchronous modes
• Cell checker
• USB 5V output

SPECIFICATIONS

• Input: 7-28V@MAX30A
• Battery Type: LiPo LiHV LiFe Lion@1-6S
• NiMh @1-16S Pb @1-10S
• Bal Cur. : 800mA @2-6S
• Accuracy: <0.005V
• Charging Power: 0.1-15A@250W *2（Asynchronous mode）
  0.1-25A@500W（Synchronous mode）
• Discharging Power:
  0.1-15A@250W x 2 Recycle Mode
  0.1-3A@12W x 2 Normal Mode
• USB: 2.1A@5V upgrade@USB3.0
• Battery Voltage: 1.0V-5.0V @1-6S
• Battery Internal Resistance: 1-100mR @1-6S
• Display: LCD IPS 2.4 inch 320x240 resolution

DIMENSIONS

• Size: 98mm x 68mm x 35mm
• Weight: 220g
• Size: 108.5mm x 80.5mm x 46mm
• Weight: 300g

INCLUDES

1x ToolkitRC M6D Dual Channel 500W 25A DC Battery Charger
