Toolkit RC M8S Charger

TOOLKITRC M8S 400W 18A CHARGER

The M8S is a worthy upgrade over the previous version, the M8. The M8S adds extra power to 400W, amperage now at 18A, and a full-color display! You can even test your Sbus/PWM/PPM signals with this charger!

FEATURES

• 2.4" Color Screen
• Battery Charger
• Cell Checker
• Servo Tester
• PWM,PPM.SBUS Input/output Receiver & Flight control tester
• Viable AMp/volt DC Power supply (Required external DC input)

SPECIFICATIONS

• Charging
• Input 7-30V: @MAX18A
• Battery Type: LiPo LiHV LiFe Lion @ 1-8S NiMh @1-20S Pb @1-12S
• Bal Current: 800mA @2-8S
• Accuracy: 0.01V
• Charging Power 0.1-18A @ 400W
• Discharging Power 0.1-18A @ 400W
• Recycle Mode 0.1-5A @ 20W Normal Mode
• USB 2.1A @ 5.0V upgrade

MEASURING

• PWM 880us-2200us @20-400Hz
• PPM 880us-2200us 8Ch @20-50hz
• SBUS 880us-2200us 16ch @20-100Hz
• Voltage 1.0V-5.0V @1-8S
• IR 1-100mR @1-8S

OUTPUT

• PWM 500us-2500us @20-1000Hz
• PPM 880us-2200us 8ch @50hz
• SBUS 880us-2200us 16ch @74Hz
• Power 1-18A @ 1-30V Mode: CC+CV
• Display:LCD TFT 2.4 inch 320x240 resolution

PRODUCT

• Size 98mm x 68mm x 35mm
• Weight 170g
• Packing: Size 108.5mm x 80.5mm x 46mm
• Weight 255g

INCLUDES

1 x ToolkitRC M8S 400W 18A Charger
