DLE 130 Twin
ArrayR 17600,00
Description
| FEATURES |
- Newly designed circuitry and software in the electronic ignition provides better idle, improved transition and alllows a wider range of ignition battery voltages from 4.8-12V
- Anodized billet aluminum prop drive for lower vibration
- Advanced CNC machining improves fit and finish of each part
- Two petal V-type reed valve carburetors
- Cast aluminum manifold for added rigidity
- Increased contact area of piston to cylinder for longer life
- Three bearing crankshaft
| INCLUDES |
- DLE 130cc Twin Cylinder 2-Cycle Gasoline Engine
- Two Mufflers with Teflon Extensions
- Two Spark Plugs
| REQUIREMENTS |
- Fuel Mixture: 30:1
- Fuel Octane Level: 93
- Oil: High quality 2-cycle
- Propeller: 27x12, 28x10, 28x11, or 29x9
- Ignition Battery: 4.8-12V
| SPECIFICATIONS |
- Displacement: 7.93 cu in (129.94cc)
- Bore: 1.85" (47mm)
- Stroke: 1.47" (37.5mm)
- Compression Rate: 9.2:1
- Output Power: 13HP at 8,500 RPM
- Idle Speed: 1,300 RPM
- Static Thrust: 62.8lbs (28.5kg) / 328ft (100m) Altitude
- 54.0lbs (24.5kg) / 5,900ft (1,800m) Altitude
- Spark Plug: DLE-6
- Spark Plug Gap: 0.018-0.020" (0.45-0.51mm)
- Installation Torque: 7-8lbs ft
- Break-in Procedure: Break in at 3,500RPM for 2 hours running at various speeds. Do not run at low speed for extended period of time, or carbonization of the spark plugs may result
- Weight Engine Only: 5.59lbs (2,540.1g)
- Total Weight: 6.94lbs (3,152.3g) including mufflers and muffler hardware, ignition, mount standoffs, and spark plugs
